RMG Solution
rack
Split stacking rack
Our stack racks are movable, stackable storage systems designed to handle virtually any product. Size, capacity, and quantity can be tailored to fit your operation.
Material:
- 50*50*1.5mm/30*30*1.2mm
- /25*50*1.5mm galvanized pipe, iron plate 1.0mm 2.
- Technical process description: welding,
- Using carbon dioxide shielded welding, steel pipe welding
- Even surface. Spraying process, using epoxy
chain style
Split stacking rack (chain style)
Material:
- 50*50*1.5mm/30*30*1.2mm
- /25*50*1.5mm galvanized pipe, iron plate 1.0mm 2.
- Technical process description: welding,
- Using carbon dioxide shielded welding, steel pipe welding
- Even surface. Spraying process, using epoxy
shelf
Accessories shelf
Material:
- Size: 2100*700*2280mm*3
- Layer, layer spacing 600mm 2.
- Material: Material: Column: 50*60*
- 1.2C section steel, beam: 40*60*1.2P, Section steel.
- secondary beam: 20*30*1.2 galvanized pipe, 30*30 square mesh sheet 4, technical.
- process description: carbon dioxide protection.
- Protection welding, the welding surface of the steel pipe is uniform. each
- Anti-rust work such as pickling and phosphating on the surface of steel parts.
- Process, using epoxy resin powder static Electric high temperature spraying.
Loose cloth
Loose cloth rack (4 layers)
Material:
- Size: 2000*730*1750mm*4 layers
- Material: Column: 40*80*1.5mm plus 30*50*1.5 galvanized pipe, Base: 40*80*1.5mm galvanized pipe, laminate: outer frame 20*30*1.0mm galvanized pipe plus 30*30 square mesh, 2 universal and 2 fixed 6 inch biaxial PU anti-twist wheel.
- Technical process description: carbon dioxide shielded welding is used for welding, steel pipe. The welding surface is uniform, and there are no slag inclusions, pores, welding bumps, and welding wire ends at the welding point. Undercut and splash. The spraying process, the surface of each steel part is pickled and phosphate, etc. Rust treatment, using epoxy resin powder electrostatic high temperature spraying, coating evenly.
cutting rack
Three-tier cutting rack
Material:
- Size: 1000*1000*1980mm.
- Material: main frame 30*30*1.2mm galvanized pipe 0.8mm Iron plate, the laminate is 30*30 square mesh laminate,
- Technical process description: use carbon dioxide protection for welding, the welding surface of the steel pipe is uniform, and there is no slag and gas at the welding point.
- Holes, weld flashes, wire tip undercuts and spatter. spraying process, The surface of each steel part is treated with anti-rust technology such as pickling and phosphating. Electrostatic high temperature spraying with epoxy resin powder, uniform coating.
cutting machine
Computer cutting machine rag frame
Material:
- 2400L*750W*550H/880Hmm
- Material: tripod 30*30*1.2 galvanized square tube plus non-slip feet, laminate 18mm multi-layer melamine board, red edge.
- Technical process description: carbon dioxide shielded welding is used for welding, The welding surface of the steel pipe is uniform, and there are no slag inclusions, pores, and welding at the welding point. Bumps, wire tip undercuts and spatter. Spraying process, each steel table. The surface is treated with anti-rust processes such as pickling and phosphating, and epoxy resin is used. Powder electrostatic high temperature spraying, uniform coating.
cutting rack
Hot label auxiliary table
Material:
- Size: 1500*500*770mm (including foot height 150mm
- Material: main frame 30*30*1.2mm galvanized pipe 0.8mm Iron plate, the laminate is 30*30 square mesh laminate,
- Technical process description: use carbon dioxide protection for welding, the welding surface of the steel pipe is uniform, and there is no slag and gas at the welding point.
- Holes, weld flashes, wire tip undercuts and spatter. spraying process, The surface of each steel part is treated with anti-rust technology such as pickling and phosphating. Electrostatic high temperature spraying with epoxy resin powder, uniform coating.
staff stool
Staff stool
Material:
- Size: 600*280*470mm
- Material: tripod 25*25*1.2 galvanized square tube plus non-slip feet. Cushion, laminate 18mm multi-layer melamine board, red edge seal side.
- Technical process description: use carbon dioxide protection for welding, the welding surface of the steel pipe is uniform, and there is no slag and gas at the welding point. Holes, weld flashes, wire tip undercuts and spatter. spraying process, The surface of each steel part is treated with anti-rust technology such as pickling and phosphating. Electrostatic high temperature spraying with epoxy resin powder, the coating is uniform.
water
Water table
Material:
- Size: 2400*500*770mm.
- Material: tripod 30*30*1.2mm galvanized square tube for protection Sliding foot pad, laminate 18mm multi-layer melamine board, red edge.
- Technical process description: carbon dioxide is used for welding Protection welding, the welding surface of the steel pipe is uniform, and there is no slag inclusion at the welding point, porosity, weld flash, wire tip undercut and spatter. spray process, the surface of each steel part is subjected to anti-rust processes such as pickling and phosphating Treatment, using epoxy resin powder electrostatic high temperature spraying, The coating is uniform.
Garment Storage
Garment Storage Cart
Material:
- Size: 1200*1200*800mmH (+120mm foot height)
- Material: main frame 30*30*1.2 plus 10*20*1.2mm plated Zinc tube, laminate 16mm moisture-proof board.
- Technical process description: carbon dioxide shielded welding is used for , The welding surface of the steel pipe is uniform, and there is no slag inclusion, pores, Weld flash, wire tip undercut and spatter. Spraying process, each steel part The surface is treated with anti-rust processes such as pickling and phosphating, and epoxy resin is used. Grease powder electrostatic high temperature spraying, uniform coating.
QC cart
QC cart boy
Material:
- Size 600*570*940+500mm stencil width 900mm.
- Material 30MM*30MM*1.2MM plus 30MM*30MM galvanized screen, laminate; 18mm multi-layer melamine board, red plastic edge-sealing bottom plate; 16mm. Moisture-proof board, casters: 3-inch double-axis PU anti-twisting wheel.
- Technical process description: welding, Using carbon dioxide shielded welding, the welded surface of the steel pipe is uniform. spray. Process, using epoxy resin powder electrostatic high temperature spraying.
Packing
Packing table
Material:
- Size: 2400*1600*870mm/900+600mm W.
- Material: 40*40*1.2mm galvanized square tube with horizontal adjustment Cushion, laminate 18mm multi-layer melamine board, red edge banding.
- Technical process description: carbon dioxide shielded welding is used for welding. The welding surface of the steel pipe is uniform, and there is no slag inclusion or porosity at the welding point, weld flash, wire tip undercut and spatter. spraying process, each The surface of steel parts is treated with anti-rust processes such as pickling and phosphating. Electrostatic high temperature spraying of epoxy resin powder, uniform coating.
Clothes coded
Clothes coded shelf (five grids and three layers)
Material:
- Size: inner space 1200*700*2280mm*3 layers, , Column and back sealing net.
- Material: Material: Column: 50*60*1.2C Section steel, beam: 40*60*0.8P section steel, secondary beam : 20*30*1.2 galvanized pipe, 30*30 square mesh Laminate.
- Technical process description: carbon dioxide shielded welding, The welded surface of the steel pipe is uniform. The surface of each steel Anti-rust process such as pickling and phosphating, using epoxy. Resin powder electrostatic high temperature spraying.
Hangers
Hangers
Material:
- Size: 2060*570*(780+930+170)mm
- Material: tripod 30*30*1.2 galvanized square tube plus 25 rounds Tube, 3 inch casters with brake.
- Technical process description: use carbon dioxide protection for welding, the welding surface of the steel pipe is uniform, and there is no slag inclusion at the welding place, Blowholes, weld flashes, wire tip undercuts and spatter. sprayer The surface of each steel part is subjected to anti-rust processes such as pickling and phosphating. management, using epoxy resin powder electrostatic high temperature spraying, coating uniform layer.
Scrap truck
Scrap truck
Material:
- Size: 1200*460*770/200mmH
- Material: 20*20*1.2 plus 30*30*3mm screen, laminate 0.8mm Punching plate, 4 universal 2-inch dual-axis PU anti-twisting wheels with brakes.
- Technical process description: carbon dioxide shielded welding is used for welding, steel pipe 460 The welding surface is uniform, and there are no slag inclusions, pores, welding flashes, and welding wires at the welding point. Head undercut and splash. Spraying process, the surface of each steel part is pickled and phosphate and other anti-rust process, using epoxy resin powder electrostatic high temperature spraying, , the coating is uniform.
Rabbit car
Rabbit car
Material:
- Size: 1600*800*1600mm (as long as 4 iron pillars can be inserted and removed, 2 large directional wheels in the middle, 4 small universal wheels at the corners
- Material: 50*50*1.5mm galvanized pipe.
- Technical process description: carbon dioxide shielded welding is used for welding, steel pipe welding The surface is uniform, and there is no slag inclusion, porosity, welding flash, undercut and splash. Spraying process, the surface of each steel part is subjected to anti-rust processes such as pickling and phosphating It adopts epoxy resin powder electrostatic high-temperature spraying, and the coating is uniform.
